唯卓仕 Viltrox DC-70EX单反监视器3G-SDI/HDMI双接口索尼摄像机微单相机导演7英寸监视器视频4K 70EX

唯卓仕DC70EX是一款便携式7英寸LCD监视器，可帮助您更清楚地看到影像拍摄
高品质的照片。可提供佳的高质量画面除了优异的画面之外还具有佳的
移动灵活性和作为便携小型监视器所需要的性能在包括演播室监视、室外直播、
数字电影的采集、现场制作、编辑工作室，甚至研究和开发在内的多种专业
监视应用中。
Viltrox DC-70 EX is a portable 7" LCD monitor which can help you shoot high quality
otos. It can provide excellent high definition picture quality. Apart from it, it also
featuring great flexibility and portability. It is perfectly used for: Seminar, Out door
real time broadcasting, Recording of digital movie, on site production, Editing.
Monitoring and recording in R&D.
7英寸液晶显示屏、分辨率高达1024*600像素
7 inch LCD screen, 1024*600 pixels
支持HDM/SDAV/ TALLY信号输入
Support HDMI/SDI/AV/TALLY signal input
支持扬声器，耳机、卡侬接口
Support Loudspeaker, headphone port 3.5 and XLR port
具有聚焦、亮度直方图、音频柱、峰值等功能
Featuring the functions of focusing, histogram, volume bar, peaking
标配加长型遮光罩、避免强光的干扰
Standard longer hood to avoid strong light interference


液晶屏 Screen
7英寸nch
屏幕显示 LCD display分辨率 Resolution
1024*600像素 Pixel
亮度 Brightness
1000cd/
输入信号接口 Input Jack HDM、AN、SD、TALY
输出信号接口 Output Jack HDM、sDl
音频 Audio
扬声器 Loudspeaker、耳机插口 Headphone port中3.5
固件升级 Firmware upgradeUSB升级端囗 Upgrade port
电源接口 Power supply
DCN输入nput(电源适配器插口 power port)，卡依接口 XLR port
电源
适配电源 Power adapter
DC 8V-18V
Power supply
可充电电池 Chargeable battery NP-Fs55/F570/770160/970
工作环境
操作温度 Operating temperature+0to+40°(+32to+104°
Working temperature
储存温度 Storage temperature
20to+60°C(4to+140°)
尺寸 Dimensio
191mm x 148mm x 45mm
重量 Weight
约 Approx.620g(不包括电池 excluding battery)
转接座 Hot shoe*1遮阳罩 Sun shade hood*1布袋 Pouch*1
附带配件AC5HMc高清线 pe A-Type C*1 HDMI Type D(HDMIA-M
