阿童木史努比 atomos shinobi shinobi7 英文版说明书下载 使用手册 pdf 免费 操作指南 如何使用 快速上手
| MSRP | |
|---|---|
| USD | $299.00 |
| EUR | €299.00 |
| Physical Specifications | |
| Dimensions (W x H x D mm) | 151 x 91.5 x 31 |
| Weight | 196g / 7oz. |
| Mount points | 1 x Anti rotation 1/4" / 3/8 top and bottom |
| Environmental | |
| Ambient operating temperature | Up to 40° C |
| Construction and Control | |
| Body | Polycarbonate ABS Plastic |
| Cooling | Passive |
| Multi-function button | Power / lock Screen |
| Power | |
| Input voltage | 6.2V - 16.8V |
| Operating power | 5.8V - 7.2V |
| Compatible batteries | NPF L series |
| Built in battery | No |
| Battery Run time (Monitor only) | Monitor |
| Continuous power | 2600mAh - 1.5hrs, 5200mAh - 3hrs, 7800mAh - 6hrs |
| DC in connector | Via DC Jack on Optional Battery Eliminator |
| Dtap | Via optional Battery Eliminator and DTap to DC cable |
| Display | |
| Touchscreen | SuperAtom IPS panel (capacitive touch) |
| Size | 5.2" |
| Resolution | 1920 x 1080 |
| PPI | 427 |
| Bit depth | 10-bit (8+2 FRC) |
| Backlight Type | Edge lit |
| Brightness (cdm2 / nits) | 1000 |
| Aspect ratio | 16 : 9 |
| Color Gamut | Rec.709 |
| Calibration support | Atomos Calibrator with Xrite i1 Display Pro / Plus (Retail) |
| Color Pipeline | |
| Gamma | Sony SLog / SLog2 / SLog3, Canon CLog / CLog2 / Clog3, Arri Log CEI160 / LogCEI200 / LogCEI250 / LogCEI320 / LogCEI400 / LogCEI500 / LogCEI640 / LogCEI800 / LogCEI1000 / LogCEI1280 / LogCEI1600, Panasonic Vlog, JVC JLog1, Red LogFilm / Log3G10 / Log3G12, FujiFilm Flog, PQ (HDR10), HLG, Nikon N-Log |
| Gamut | BT2020, DCI P3, PDCI p3 65, Sony SGamut / SGamut3 / SGamut3.cine, Canon Cinema / DCI P3 / DCI P3+ / BT2020, Panasonic V Gamut, Arri Alexa Wide Gamut, Rec709, JVC LS300, Red DragonColor / DragonColor2 / RedColor2 / RedColor3 / RedColor4 / RedWideGamut |
| 3D LUT Display | .Cube Format |
| 3DLUT 50/50 | Yes |
| Monitoring Modes | Native / HLG / PQ / 3D LUT |
| HDR output Conversion | No |
| Video Input | |
| HDMI | 1 x HDMI (1.4) 4k p30 |
| HDMI RAW | No - Video only |
| SDI | No - HDMI only |
| SDI RAW | No - HDMI Video only |
| Bit Depth | 8/10-bit Video |
| Video Chroma Subsampling | 4:2:0 & 4:2:2 |
| Audio In/Out | |
| HDMI | 2ch 24Bit, input dependent |
| Headphone out | 3.5mm 2ch. |
| Resolution and Frame Rates (Record, Monitor & Playback) | |
| 4k DCI | Monitor Only: 23.98p, 24p, 25p, 29.97p |
| 4k UHD | Monitor Only: 23.98p, 24p, 25p, 29.97p |
| FHD 1920 x 1080 Progressive | Monitor Only: 23.98p, 24p, 25p, 29.97p, 50p, 59.94p |
| 1280 x 720p | Monitor Only: 50/59.94/60p |
| Supported media | |
| SD | SD Card slot for LUTs / Firmware |
| File System | ExFAT |
| On screen tools | |
| MultiScope Analysis View | Image, selectable Waveform, Histogram Vector Scopes and Audio bars |
| Waveform | Yes, 3 size / position |
| Histogram | Luma and RGB |
| RGB parade | Yes, 3 size / position |
| Vector scope | Yes, 2 size / position |
| 1 x Zoom | Yes. 1:1 Pixel mapping for 4k |
| 2 x Zoom | Yes |
| 4 x Zoom | Yes |
| Focus peaking | Colour selected / threshold setting / color / mono / edges only |
| False colour | Yes |
| Zebra | Yes, adjustable |
| Isolate color channel | Blue Only |
| Cine Frame Guides | 2.4:1, 2.35:1, 1.9:1, 1.85:1, 4:3 |
| Anamorphic desqueeze | 1.33x , 1.5x ,2x |
| Display Flip | Vertical and Horizontal selfie mode |
| What’s in the box | |
| Accessories included | Shinobi unit, 1x international power supply and Quick Start guide |
| Optional extras | Power kit, HDMI cables, USB to serial cable, Sunhood |
| Warranty | |
| Standard | 1 year. |
